30 Inch Linear Shower Drain Brushed Nickel Linear Wedge Design by SereneDrains

Also Available In: 16", 24", 30", 35", 39", 47", 59".
In stock ready to ship. FREE SHIPPING

Drain Includes: 100% stainless steel brushed nickel channel body & grate, puller key, rubber gasket, waterproofing membrane sheet around the drain flange (not required but included), Installation Instruction.

Applications: Shower & bath, kitchen, pools, balconies, hotel rooms, gym, spa etc.

Perfect for wheelchair access & barrier-free showers (walk in floor plans).

Features:

• Stainless steel brushed nickel finish.
• Shower Grate is grade 6 gauge (5mm) 304 stainless steel.
• Foot friendly grate with anti-slip nodules.
• Superior quality laser cut electropolish finish.
• Bodies are fully welded and leak tested prior to dispatch.
• 2 Inch diameter central vertical outlet.
• Designed to be installed into any 2" shower drain flange.
• Compatible with tiles up to 10mm depth (14mm lip).
• Sized to match standard 1/2", 1", 2, and 4" tile without cutting.
• Pre-Slope channel. Channel width: 2 3/4" (70 mm).
• Flow rate: at entrance of shower - 6.3GPM (0.4 l/s); against the wall - 9.5GPM (0.6 l/s).
• Flange body edge designed for use with all types of waterproofing: hot mop, painted or liquid membranes, sheet membrane, vinyl waterproofing etc.


Available accessories include plumbing connectors (ABS/ PVC flange) and debris strainer.

30 day return policy. Money back guarantee.
Contact us for quantity discounts
