SereneDrains Matte White Tile Insert Linear Shower Drain Kit with Hair Catcher and Flange Base

Upgrade your shower with this all-in-one matte white linear drain kit, designed for smooth, hassle-free installation and a luxurious finish. The kit includes a sturdy flange base for secure mounting and a removable hair trap to help prevent clogs. Whether you're a contractor or a DIY enthusiast, this drain delivers a clean, modern look with dependable performance.

This tile insert linear drain allows you to seamlessly integrate your shower floor tile into the drain cover, creating a sleek, virtually invisible look. It’s a decorative yet functional upgrade that blends beautifully with any design.

With its elegant matte white finish, this drain adds a refined touch to contemporary and upscale bathrooms. Compatible with most waterproofing systems, it's a smart choice for stylish, streamlined shower renovations—now offered at a reduced price for exceptional value.

Note: Check local plumbing codes. Some installations may require ABS, PVC, or cast iron drain flanges—consult a licensed plumber if unsure.

What’s Included:

Stainless steel channel body & grate
Drain flange base with rubber gasket
Removable hair trap
Puller key
Waterproofing membrane sheet (optional but included)
Installation instructions

Key Features:

Durable stainless steel with matte white finish
Laser-cut, electropolished grate for a refined look
Leak-tested, fully welded body
2" central vertical outlet—fits standard 2" shower drain flanges
Works with tile depths up to 10mm (14mm lip)
Pre-sloped channel for efficient drainage
Channel width: 2 ¾" (70mm)
Compatible with standard ½", 1", 2", and 4" tiles—no cutting needed
16-gauge 304 stainless steel
Flow rates:
- 6.3 GPM (0.4 L/s) at shower entrance
- 9.5 GPM (0.6 L/s) against the wall
Ideal for wheelchair-accessible and barrier-free showers
Flange edge compatible with all waterproofing methods: hot mop, liquid membrane, sheet membrane, vinyl, and more

Dimensions:

Net Size (inches/mm)	Overall Size (inches)	Intake Area (sq. in.)
15 ¾" x 2 ¾" (400mm)	17 ¼" x 4 ⅜"	12.38
23 ½" x 2 ¾" (600mm)	25.2" x 4 ⅜"	14.96
30" x 2 ¾" (762mm)	31.57" x 4 ⅜"	17.62
35 ⅜" x 2 ¾" (900mm)	37.01" x 4 ⅜"	20.03
39 ⅜" x 2 ¾" (1000mm)	40.95" x 4 ⅜"	21.12
47 ¼" x 2 ¾" (1200mm)	48.82" x 4 ⅜"	26.68
59.05" x 2 ¾" (1500mm)	60.63" x 4 ⅜"	31.67

Also available: Need a specific drain size or outlet location? Explore our collection of Custom Length Linear Shower Drains — perfect for personalized shower layouts and unique design requirements.

We also carry Side Outlet Linear Shower Drains in multiple sizes, offering flexible solutions to match any bathroom style and installation need.

Additionally, check out our Tile Insert Linear Shower Drains with a center outlet — available in Brushed, Gold, Matte White, and Matte Black finishes.

In stock and ready to ship from the USA. Free Shipping.
