Shower Drain Side Outlet Adapter with Brushed Linear Shower Drain, Wedgewire Design by SereneDrains
Relocating a shower drain can be challenging and costly, often requiring extensive demolition and concrete work. Our Shower Drain Side Outlet Adapter solves this by allowing your drain to connect to existing plumbing away from the new location—reducing mess, demolition, and overall installation costs.
SereneDrains linear drains feature smart construction for easy installation. The Flange Body Edge provides excellent stability by allowing the flange to rest directly on the floor edge and is compatible with various waterproofing materials, including hot mop, liquid membranes, sheet membranes, and vinyl waterproofing.
Made from (5mm) 6 gauge Stainless Steel 304 Grate for durability, these drains include a pre-slope channel measuring 2 3/4" (70 mm) for optimal water drainage. Together with our Horizontal Side Discharge Outlet, which facilitates installation to existing horizontal plumbing, our drain reduces the need for extensive modifications. The Linear Wedge Design linear shower drain transforms any shower into a high-end space, offering both durability and modern style for an exceptional shower experience.
Available in 16", 24", 30", 35", 39", 47", and 59" Lengths.
Includes: Stainless steel channel body and grate cover, puller key, hair trap, waterproofing membrane sheet, and installation instructions.
Side Outlet Converter Includes: Base discharge and rubber fitting. An extension fitting is also available to increase the drain connection height if needed.
Value: Save $40.99 when you purchase this bundle.
Drain Features:
- 6 gauge 304 stainless steel brushed finish.
- Superior quality laser cut electro-polish finish.
- Bodies are fully welded and leak tested prior to dispatch.
- 2-inch diameter central vertical outlet.
- Designed to be installed into any 2" shower drain flange.
- Compatible with tiles up to 10mm depth (14mm lip).
- Sized to match standard 1/2", 1", 2", and 4" tile without cutting.
- Pre-slope channel. Channel width: 2 3/4" (70 mm).
- Flow Rate: At entrance of shower - 6.3 GPM (0.4 l/s); against the wall - 9.5 GPM (0.6 l/s).
Additional Benefits:
-
Flange body edge designed for use with all types of waterproofing: hot mop, painted or liquid membranes, sheet membrane, vinyl waterproofing, etc.
-
Improved Water Drainage: Efficiently handles a larger volume of water, preventing pooling.
-
Better Slope Management: Allows the shower floor to have a single slope toward the drain, simplifying design and construction.
-
Enhanced Accessibility: Ideal for walk-in showers and barrier-free environments.
-
Reduced Clogging: Designed to minimize the likelihood of clogs and make them easier to clear.
-
Space Efficiency: Perfect for bathrooms with limited floor thickness, such as in older homes or buildings with shallow floor cavities.
-
Flexible Plumbing: Simplifies connections to existing horizontal plumbing, reducing the need for extensive modifications.
SereneDrains Linear Shower Drains and Square Drains with Horizontal Side Discharge Outlet are available in a variety of designs, finishes, and sizes.
30 day return policy. Money back guarantee.
Contact us for quantity discounts.
In Stock Ready To Ship
